EBOX V3 60 - PRE ORDER

Not to be confused with the Ebox 3 72v!
The EBOX V3 has finally arrived! You wanted more power, more punch, more range, more control and a higher top speed?? We listened to you, and we delivered all of that and more, featuring the brand new EBX powertrain!
Bigger batteries, a Fardriver 80A controller and a high power PMSM motor with encoder and temperature feedback with up to 6.3kW. There are no hall sensors to fail and the precise control of the encoder, provides laser sharp coil firing for increased efficiency and maximum performance.
Added to that we have included a colour TFT display with 3-speed modes and fault-finding capability. Our warranty has been increased to 1 year, (or 1000 miles) on all powertrain components (battery, controller, motor). What does this mean? Basically, peaking top speeds of up to 55 mph! New colourways, new tyres and all in the same mini package you can throw in the trunk of your car.
Frame Design
Double Cradle V3 wide frame (183mm), race inspired revised geometry. Increased fork travel, increased pre-load and heavier oil. Standard Footpeg.
Bar Risers
Alloy Cast 36mm rise Ø22.2
Handlebar
6061 T6 EBOX High Rise 1pc
Front Suspension
150mm travel USD
Wheel Size
14/12
Tyres
60/100-14 & 80/100-12 Dirt
Front Brake
Hyraulic Disc (Right lever) e-moto brakes, 180mm rotor, 4 bolt
Rear Brake
Hyraulic Disc (Left lever) e-moto brakes, 180mm rotor, 4 bolt
Gearing
Front 10T, rear 70T
Chain
219H 108L
Motor
60V EBX PMSM motor with temp feedback and encoder
Motor Voltage
60V
Peak Power
3.7KW (5hp)
Rated Power
3.3KW
Max RPM
7,500
Battery
60v 18.2Ah battery 18,600 cells with QS8 connector
Controller
80 Amp fardriver controller
Throttle
SURRON style full twist
Display
TFT odometer display with 3 speed modes and fault code analysis software
Connectors
Automotive connectors with sealed wiring harness
Charger
AC 100-240V, Output: 67.2V, 3A
Charge Time
5-6 hours
Range Per Charge
21-25 miles (35-40Km)
External Adjustability
3 riding modes
Top Speed
45mph (72Km/h)
Waterproof
IP54
Wheelbase
980mm
Seat Height
650mm
Built to Race
B2R
Warranty
EBX 1 year/1000 miles (whichever comes first) powertrain warranty. 6 month parts warranty
